Classic SAIP AH780 – 780Kw
Industrial Wind Turbine System SAIP AH780
SAIP AH780 Wind Turbine
Technical Data: SAIP AH780
- Nominal power (kW) 780
- Cutting wind speed(m/s) 3.5
- Nominal wind speed(m/s) 14
- Cutout wind speed(m/s) 25 (10 minutes mean value)
- Survival wind speed(m/s) 70 (3s mean value)
- Rotor diameter: 50m
- Rotational speed(rpm) 22
- Blade material Glass fiber
- Blade length(m) 23.5
- Blade number 3
- Swept area(m2) 1962
TECHNICAL SAIP AH780
- Gearbox Type Three stage with planetary and spur
- Nominal power(KW) 825
- Ratio 1:67.4
- Brake system Primary Brake System Three individual Tip-break
- Secondary Brake System 2mechanical brake on the high-speed shaft
- Generator Primary Brake System Three individual Tip-break
- Nominal power(KW) 780
- Nominal voltage(V) 690
- Yaw system Type Active yawing
- Yawing speed(0/s) 0.68
- Control system Controller Type Plc
- Towers Type tubular steel tubular Tubular steel
- Tower height(m) 47.28/62.92
- Weight Nacelle 22T
- Rotor 14T
- Tower 53T/47.28m@76.2T/62.29m
Shipping Options (Canada):
- Ship SAIP AH780 Direct – Shipped directly to your door.
- Dock Pick-up – Pick up at your nearest seaport dock FOR FREE! (Direct from MFR)
- Custom Quote by email based on the total weight of shipment & your location.
Shipping Options (US):
- Custom Quote by email based on the total weight of shipment & your location.
MWPS Global can assist in worldwide shipping & transportation as well as full refurbishing and upgrade services at highly competitive prices.
MWPS Global works with highly skilled re-manufacturers, refurbishers, and machinists if upgrades or refurbishing is requested. This ensures the re-manufactured equipment is properly restored to the original manufacturers’ specifications and is refurbished according to our high standards. Refurbished wind turbines offered by MWPS Limited are completely disassembled and thoroughly inspected and cleaned. Our highly experienced wind turbine refurbishment affiliates evaluate the condition of the reconditioned wind turbine and replace all wear parts. The main moving components will be reconditioned to new or better than new standards. The controls, gearbox, hub, generator, hydraulic system are all thoroughly reconditioned and are either restored or replaced. All refurbished wind turbines come with a full technical report of the reconditioning work undertaken.
PLEASE NOTE
- Viewings arranged only if a signed LOI (Letter of Intention) has been received.
- No time wasters or tyre kickers, please!
